Product Name:

ABB SPAJ140C DCS PLC Module

Product Description:

The ABB SPAJ140C is a Digital Controller Module designed for use in ABB’s AC 800M and 800xA DCS (Distributed Control Systems) platforms. The module plays a crucial role in process automation, acting as the interface between the field devices and the control system, ensuring accurate data acquisition, control, and monitoring of industrial processes.

The SPAJ140C is part of ABB’s AC 800M family, which is specifically designed for high-reliability, flexible, and high-performance automation solutions in industries such as oil and gas, chemical, power generation, and manufacturing.

This module provides support for digital I/O, communication with field devices, and process control applications, making it suitable for a wide range of tasks from data acquisition to safety-critical operations. With its advanced diagnostic features and high availability, the SPAJ140C is built for use in complex industrial environments that require precision and dependability.

Product Parameters:

• Model: SPAJ140C
• Type: Digital Controller Module for ABB AC 800M and 800xA DCS
• Manufacturer: ABB
• Application: Process Automation, Data Acquisition, Control Systems
• Input/Output Types: Digital Inputs, Digital Outputs, Communication Interfaces

Product Specifications:

General Features:

• Digital Inputs:

  • Supports multiple digital input channels, typically designed for handling 24V DC signals from devices like on/off switches, position sensors, etc.

• Digital Outputs:

  • Provides 24V DC output signals for controlling binary devices such as relays, actuators, or valves.

• Communication Interfaces:

  • The SPAJ140C module supports various communication protocols, allowing it to interface seamlessly with other devices in the ABB DCS system, such as I/O modules, HMI (Human-Machine Interface), and field devices.
  • It supports protocols like Modbus, Profibus, Ethernet, and ABB proprietary protocols.

• Redundancy Support:

  • The module supports redundancy configurations to ensure high availability and fault tolerance, crucial for mission-critical applications.

• Advanced Diagnostics:

  • Includes diagnostic features for detecting faults in real time and providing operators with detailed status information to facilitate maintenance and troubleshooting.

• Programmable Logic Control (PLC) Capabilities:

  • The module includes built-in PLC functions that can execute process control algorithms, such as PID loops, interlocks, and safety functions.

• Integration with ABB DCS:

  • Seamlessly integrates with the 800xA DCS system for comprehensive process monitoring and control. The module works with other ABB components like the AC 800M controller, I/O modules, and HMIs to form a unified control system.

Electrical Specifications:

• Nominal Voltage: 24 V DC for digital inputs and outputs.

• Power Consumption: Around 10 W (depending on specific configuration and operational conditions).

• Input Voltage:

  • Digital Inputs: Typically 24V DC (range 20-30 V DC).
  • Output Voltage: Typically 24V DC outputs for controlling relays or other binary devices.

• Communication Voltage:

  • The SPAJ140C uses various communication standards (such as Modbus, Ethernet, Profibus), and each interface may have a slightly different voltage requirement for signal transmission.

Mechanical Specifications:

• Dimensions:

  • Height: Typically 125 mm (4.92 inches)
  • Width: Typically 120 mm (4.72 inches)
  • Depth: Typically 70 mm (2.76 inches)

• Weight:

  • Approximately 0.5 kg (1.1 lbs), depending on configuration.

• Mounting:

  • DIN rail mounting for easy installation in standard control panels or cabinets.

Environmental Specifications:

• Operating Temperature:

  • -10°C to +60°C (14°F to 140°F), suitable for industrial environments with temperature fluctuations.

• Storage Temperature:

  • -40°C to +85°C (-40°F to +185°F), suitable for wide range storage conditions.

• Humidity:

  • Designed to operate in environments with up to 95% relative humidity, non-condensing.

• Vibration Resistance:

  • The module is built to withstand industrial vibrations, ensuring high reliability in dynamic operational environments.
