Product Name:

GE IS200SRTDH2ACB DCS PLC Module

Product Description:

The GE IS200SRTDH2ACB is a Distributed Control System (DCS) PLC module from General Electric (GE), specifically part of the Mark VIe series of control systems. The IS200SRTDH2ACB module is designed for real-time process control, automation, and monitoring in critical industries such as power generation, chemical processing, oil & gas, and manufacturing.

This module offers high-reliability control, redundant communication paths, and advanced diagnostics to ensure maximum uptime and performance in industrial operations. It is widely used in turbine control systems, generator protection, emergency shutdown systems, and other process control applications that require fault tolerance and high availability.

The IS200SRTDH2ACB functions as an I/O interface module within the larger Mark VIe control system, facilitating communication between the controller and various field devices. It supports digital and analog inputs and outputs, enabling it to handle a variety of industrial sensors, actuators, and other process control elements.

Product Parameters:

• Model: GE IS200SRTDH2ACB
• Manufacturer: General Electric (GE)
• Type: DCS PLC I/O Module
• Application: Industrial process control, real-time data acquisition, and automation in critical systems, such as turbine control, generator protection, and emergency shutdown systems.
• System Compatibility: Part of the Mark VIe control system, designed to integrate with GE’s industrial control solutions for industries like power generation, chemical processing, oil & gas, and manufacturing.
• I/O Type: Supports digital and analog inputs and outputs for a wide variety of field devices.
• Field Devices Supported: Compatible with devices such as temperature sensors, pressure transmitters, flow meters, and actuators.
• Primary Function: Acts as an I/O interface module, providing real-time data acquisition, monitoring, and control capabilities for critical industrial processes.

Product Specifications:

General Features:

• Real-Time Process Control:
  The IS200SRTDH2ACB module is designed to provide real-time control and monitoring of industrial processes, ensuring efficient operation and rapid response to changes in system conditions. This is crucial in high-stakes environments where process stability and safety are paramount.

• Digital and Analog I/O Support:
  The module supports both digital and analog I/O signals, allowing it to interface with a wide range of industrial sensors and actuators. This flexibility enables it to control and monitor variables such as temperature, pressure, flow rate, and level across various systems.

• Advanced Diagnostics:
  The IS200SRTDH2ACB module is equipped with built-in self-diagnostics and system health monitoring tools. These capabilities help identify potential failures, alert operators, and enable proactive maintenance to minimize downtime and prevent costly disruptions in operations.

• Redundant Communication Paths:
  The module is built to support redundant communication paths, which enhances system reliability by ensuring continuous communication even in the event of a network or communication failure. This redundancy is essential for mission-critical operations where uptime is crucial.

• High Reliability for Critical Applications:
  The IS200SRTDH2ACB module is designed to function reliably in high-demand environments where failure is not an option. It is widely used in applications where system uptime and safety are critical, such as power plants and oil & gas facilities.

• Seamless Integration with Mark VIe:
  The module is part of the Mark VIe control system, designed for seamless integration with other GE industrial control solutions. This ensures centralized control and monitoring across the entire automation system, improving operational efficiency and safety.

Electrical Specifications:

• Power Supply:
  The IS200SRTDH2ACB module operates on a 24 V DC power supply, which is typical for many industrial control and automation systems.

• Power Consumption:

  • Typical Power Consumption: 7W to 20W, depending on the configuration and the number of active I/O points.

• Input Voltage:

  • 24 V DC (nominal)
  • Voltage Tolerance: ±10% typical.

• Current Consumption:
  The current consumption is approximately 300mA to 700mA, depending on the configuration and the number of active I/O channels.

• Communication Protocols:
  The IS200SRTDH2ACB module supports multiple communication protocols for data transmission, including Modbus RTU, Ethernet/IP, and GE’s proprietary communication protocols. This allows seamless integration with other control devices, sensors, and controllers.

Mechanical Specifications:

• Dimensions:
  The IS200SRTDH2ACB module is designed for installation in standard 19-inch rack-mounted or DIN rail-mounted enclosures, with compact dimensions that ensure easy integration into control cabinets.

• Weight:
  The module weighs approximately 1.5 kg to 2 kg, depending on configuration and installed options.

• Mounting:
  The module is designed for rack-mounted or DIN rail-mounted installation in control systems, ensuring secure and organized setup within control cabinets or panel enclosures.

Environmental Specifications:

• Operating Temperature Range:

  • -40°C to +70°C (-40°F to +158°F), ensuring reliable performance in extreme temperature conditions commonly found in industrial environments.
